Mac Plus

Posted by musovern on Apr 16th, 2018 in Macintosh, Vintage Computers | 0 comments

The Macintosh Plus computer was the third model in the Macintosh line, introduced on January 16, 1986, two years after the original Macintosh and a little more than a year after the Macintosh 512K, with a price tag of 2599 USD. As an evolutionary improvement over the 512K, it introduced RAM expansion from 1 MB to 4 MB, and the SCSI peripheral bus, among smaller improvements. It originally had the same generally beige-colored case as the original Macintosh (“Pantone 453”), but in 1987, the case color was changed to the long-lived, warm gray “Platinum” color.















Macintosh Plus
Release date January 16, 1986
Introductory price $2599
Discontinued October 15, 1990
Operating system 1.1–2.1, 3.0–6.0.8, 7.0-7.5.5
CPU Motorola 68000 @ 7.8 MHz
Memory 1 MB, expandable to 4 MB (150 ns 30-pin SIMM)
Graphic Mode 512 x 342 dots
Monochrome
Tone Generator & Digital-Analog converter (22KHz sampling rate)
Size/Weight 34.5(H) x 24.5 (W) x 27.5 (D) cm / 7.48 kg
I/O Ports RS 232/422 x 2 for printer and modem, SCSI, external F.D. unit, ext. loudspeaker
One 3.5” 800 KB disk-drive
OS: Macintosh System (from 3.2 to 7.5)
